Startseite /Produkte/Patientenmonitor im Krankenhaus/Multi Parameter ICU Patient Monitor Portable ECG Patient Monitor Hospital Patient Monitor Price

Multi Parameter ICU Patient Monitor Portable ECG Patient Monitor Hospital Patient Monitor Price

1 Piece
MOQ
$1,784.00(1 - 19 Pieces) $1,729.00(20 - 49 Pieces) $1,665.00(50 - 99 Pieces) $1,620.00(>=100 Pieces)
Preis
Multi Parameter ICU Patient Monitor Portable ECG Patient Monitor Hospital Patient Monitor Price
Eigenschaften Galerie Produkt-Beschreibung Fordern Sie ein Zitat
Eigenschaften
Technische Daten
Model Number: iS15 Pro
Power Source: Electricity
Warranty: 1 Year
After-sale Service: Online technical support
Material: Plastic
Shelf Life: 3 years
Quality Certification: ce
Instrument classification: Class II
Safety standard: EN 149 -2001+A1-2009
Product name: Vital Signs Module Monitor NIBP SPO2 Patient Monitor Touch Screen
Model: Medical science Multi-parameter patient monitor
Display: 15" Color TFT-LED Anti-dazzling TFT-LCD
Certificate: CE ISO
Feature: ECG, SpO2 , NIBP, RESP, 2-Temp, PR
Function: First-Aid Devices, Examination Therapy Equipments
ECG: 3 Leads /5 Leads/12 Leads
Standard parameters: ECG,SPO2,NIBP,PR,RESP,TEMP,ETCO2
Safety: IEC60601-1 Approved, CE marking according to MDD93/42/EEC
Nellcor-SpO2 Measurement Range: 0~100%
Grundinformation
Zertifizierung: ce, CE ISO
Model Number: iS15 Pro, Medical science Multi-parameter patient monitor
Zahlung und Versand AGB
Packaging Details: Package included: 1XiS15Pro 15" TFT-LCD Semi-modular Patient Monitor 1X Adult Reusable Finger clip SpO2 Sensor 1X ECG 5-Lead Cable, Snap End, IEC Standard 1X Adult Reusable NIBP Cuff 1X Adult Reusable NIBP Tube 1X Adult Reusable Skin Temperature Probe 10X
Supply Ability: 100 Unit/Units per Month
Produkt-Beschreibung
Product Description
Icu Operating Room Multiparameter Patient Monitor Emergency Equipments Medical Cardiac Defibrillator With Vital Sign Monitor
● Introduction:
iS15 pro is a High Acuity 15" Multi-Parameter Modular Patient Monitor, which can offer multiple parameter modules to choose from, adapting to the flexible parameter combination requirements in high acuity applications. With its plug-and-play modules, our modular patient monitor is able to monitor a wide range of parameters simultaneously, such as ECG, RESP, SpO2, NIBP, 2 TEMP, IBP, EtCO2, BIS, EEG, CO, ICG, AG etc adapting from critical cares to anesthesia monitoring.

Application:
It suitable for bedside, operation room, ICU, CCU etc.

● Feature:
iS15 Pro Semi-Modular Patient Monitor
15" Color LCD super Display Full Touch Screen
High-end parameter modules of M series seamlessly compatible with iS
With flexibility and freedom to pre-configure and major monitoring parameters
High-end Parameters: Suntech NIBP, CO, EtCO2, AG
Exceptional connectivity by high-speed cable or wireless Networking
Standard Configuration: 5-lead ECG, SINOHERO SpO2, NIBP, TEMP, RESP, PR, Lithium-ion Battery Option/Module: Nellcor/Masimo SpO2,
IBP, EtCO2, ICG, C.O., 12-Lead ECG, Multi-gas, Recorder, Mounting kit

Display: 15" Color TFT LCD Rolling and refreshing waveform display
Resolution:1024*768
Multi displays selectable, including Standard display ，Trend coexist display ，Large-font display ，OxyCRG dynamic view display
Trace：7 traces
Sweep speed:12.5mm/s,25mm/s,50mm/s
Indicator： Alarm indicator light ，Power indicator light ，Battery indicator light ， QRS beep and alarm sound
Interface： Parameter cable interface ，AC Power input socket ，Network interface ，External VGA interface for connection
Li-ion Battery: Rechargeable (one piece) 8 hours for charging (to 90% battery capacity) 2 hours for continuous working
Trend time： 168 hours
Alarm： User-adjustable High, Medium, and Low limits ， 3-level audible and visual alarm
Networking: Connected to central station system
Recorder: Thermal array
Waveform: 2 Channel (standard)
Real time recording
Paper width: 50mm
Print speed: 25mm/s

● Cardiac Output:
Method: Thermodilution
Measurement rage: CO:0.1-20L./min, TB: 23-43ºC, TI:0-27ºC
Resolution: CO:0.1/min, TI:0.1ºC, TB: 0.1ºC
Accuracy: CO:±5%, TB: ±0.1ºC, TI: ±0.1ºC
Parameter output: Cardiac output
Hemodynamics calculation
Multi-gas/O2
Method: Infrared Absorption
Gas accuracy: CO2:0 to 15vol%,
±(0.2vol%+2% of reading) 15 to 25vol%, Unspecified N2O:0~100vol%,
±(2vol%+2% of reading) O2:0~100vol%,±(1vol%+2% of reading)
Enf,Iso,Hal:0~8vol%,
±(0.15vol%+5% of reading) 8 to 25vol%, Unspecified Sev:0~10vol%,±(0.15vol%+5% of reading) 10 to 25vol%, Unspecified Des:0~22
vol%,±(0.15vol%+5% of reading) 22 to 25vol%, Unspecified
Data output:Fi and Etvalues
Respiration rate: 0 to 150 ±1breaths/min
Other: Up to 5 simultaneous gas concentration waveforms Agent mixture detection MAC value displayed

● Standard Configuration：
ECG, SpO2, NIBP, TEMP, PR/HR, RESP

● Optional Functions ：
EtCO2, 2IBP, C.O., Multi-gas/O2, Recorder, 12 lead ECG

● Certification：
IEC60601-1 Approved, CE marking according to MDD93/42/EECA

Product name
iS15 Pro (15" TFT) Modular Patient Monitor
Place of Origin
China
Brand Name
SINOHERO
Standard Parameters
ECG, RESP, SpO2, NIBP, and Dual- channel TEMP
Optional Parameters
EtCO2,2IBP,C.O.,Multi-gas/O2, Recorder,12 lead ECG
Material
Online technical support
After-sale Service
CE ISO
Material
ABS
Instrument classification
Class II
Safety standard
EN 149 -2001+A1-2009
Display
15" TFT anti-dazzling High Resolution Display
Resolution
800*600 pixels
Accuracy
HR±2bpm
Power Input
less than 150VA
Power Voltage
AC 100-240V 50/60Hz
Safety class
Category I
● Profermance:
ECGInput:
3-Lead or 5-Lead selectable
3 leadwire cable:RA;LA;LL or R;L;F
5 leadwire cable:RA;LA;RL;LL;V or R;L;N;F;C

Lead selection:
3-lead: I,II,III
5 lead:I，II，III，AVR，AVL，AVF, V

ECG Waveform 2 channel
Gain selection ×0.25,×0.5,×1,×2,x4,Auto
Sweep speed 12.5mm/s, 25mm/s, 50mm/s
Heart Rate for Neonate 15-350BPM
Heart Rate for Adult/Pediatric 15-300BPM
Accuracy 1bpm or 1%,whichever is greater
Resolution 1bpm
Filter Diagnostic mode:0.05-100Hz
Monitor mode:0.5-40Hz
Surgical mode:1.0-25Hz

Protection Withstand 5000VAC/50Hz Voltage in isolation
Against electrosurgical interference and defibrillation

Alarm range: Neonate：15-350bpm
Adult/Pediatric：15-300BPM
ST segment detection: Measurement range: -2.0mv to 2.0mv
Alarm range: -2.0mv to 2.0mv
Arrythmia analysis: Yes
Alarm： Yes,audible and visual alarm, alarm event recallable
Pace detection： Yes
Drug dose calculation： Yes
Stand by mode： Yes

Respiration
Method Thoracic impedance
Measurement range Neonate/Pediatric：0~150rpm
Adult：0-120rpm
Apnea alarm： No alarm,10s,15s,20s, 25s,30s,35s,40s selectable
Alarm Yes, audible and visual alarm, alarm events recallable

NIBP
Method: Oscillometric
Measurement modes: Manual/Automatic/Continuous
Displayed parameters Systolic, diastolic and MAP(mean arterial pressure)
Auto measure time: Adjustable
Measurement unit mmHg/kPa selectable
Measurement type: Systolic, Diastolic, Mean
Range of Systolic pressure Adult： 40-270mmHg
Pediatric：40-200mmHg
Neonate：40-135mmHg
Range of Diastolic pressure Adult： 10-210mmHg
Pediatric：10-150mmHg
Neonate：10-100mmHg
Range of Mean pressure Adult： 20-230mmHg
Pediatric：20-165mmH
Neonate：20-110mmHg
Accuracy ±6mmHg
Resolution: 1mmHg
Alarm: Systolic, Diastolic ,Mean
Over-pressure protection: Double safety protection

SpO2
Masimo SpO2
Measurement range: 0%~100%
Resolution: 1%
Accuracy: ±2%(70%-100%); unspecified(0-69%)
Alarm range: 0~100%
Pulse Rate Range:20~254bpm Resolution:1bpm
Accuracy:±3bpm
Alarm range:0~254bpm

Temperature
Measurement range: 0~50ºC
Resolution: 0.1ºC Accuracy: ±0.1℃
Channel: T1、T2、TD

IBP
Channels 1 or 2 selectable
Measurement range -50~400mmHg
Resolution 1mmHg
Alarm: Systolic, Diastolic ,Mean
Over-pressure protection: Double safety protection

ETCO2
Measurement range 0-99mmHg
Accuracy 0 to 40mmHg ±2mmHg
41 to 76mmHg ± 5mmHg
77 to 99mmHg ±10mmHg
Sample flow rate Minimum: 50ml/m-7.5ml/m
Maximum: 50ml/m+15ml/m
Start-up time <1min,once the module starts up, it reaches ISO After 1 min,enter the full accuracy mode
Respiration rate 0 to 120rpm Respiration rate accuracy ±2 rpm
Response time：<240msec（10% to 90%）

Cardiac Output
Method: Thermodilution
Measurement rage: CO: 0.1- 20L./min.
TB: 23- 43ºC
TI: 0 - 27ºC
Resolution: CO:0.1/min.
TI: 0.1ºC
TB: 0.1ºC
Accuracy: CO: ±5%
TB: ±0.1ºC
TI: ±0.1ºC
Parameter output: Cardiac output
Hemodynamics calculation
Multi-gas/O2 Method: Infrared Absorption
Gas accuracy: CO2: 0~ 15vol%, ±(0.2vol%+2% of reading)
15~25vol%, Unspecified
N2O: 0~100vol%, ±(2vol%+2% of reading)
O2: 0~100vol%,±(1vol%+2% of reading)
Enf,Iso,Hal: 0~8vol%, ±(0.15vol%+5% of reading)
8~25vol%, Unspecified
Sev: 0~10vol%,±(0.15vol%+5% of reading)
10~25vol%, Unspecified
Des:0~22 vol%,±(0.15vol%+5% of reading)
22 ~25vol%, Unspecified
Data output:Fi and Etvalues
Respiration rate: 0 to 150 ±1breaths/min
Other: Up to 5 simultaneous gas concentration waveforms Agent
mixture detection MAC value displayed
Recommend Products

NEC8

Finger Pulse Oximeter
· Integrated with SpO2 probe and processing display module · Small in volume, light in weight and convenient in carrying · Operation of the product is simple, low power consumption · SpO2 value display · Pulse rate value display, bar graph display · Pulse waveform display · The display mode can be changed

SE1208

12-Channel ECG Machine * Splendid 10” color TFT with Alpha-numeric keyboard *Simultaneous 12 leads of ECG printing(Roll or Z-fold) *Multiple USB port for connecting PC-ECG software and external printer * Excellent ECG auto-interpretation program and Pacemaker detection * Reliable and fas Network Connectivity and data transmission

JRT200

Thermometer
* LCD display
* Adopts the latest infrared technology
* Non-contact design
* High temp alarm
* Double mode, can be used to measure the temperature of human body and object surface.
* Just 1 second can measure out the body temperature,Fast & accurate reading within 1 second.
Packing & Delivery
Physical Identity:
Product size: 40.4*32.7*18.8cm
Packing size: 45*31*44cm
Net weight: 6.5kg Gross
weight: 10kg

Operation Environment:
Power Requirement: AC100-240V, 50/60Hz,140VA,1.4A-0.59A
Temperature: 0℃～40℃
Humidity: 15%～80% (non-condensing)

Certification： IEC60601-1 Approved, CE marking according to MDD93/42/EEC Package included: 1XiS15Pro 15" TFT-LCD Semi-modular Patient Monitor
1X Adult Reusable Finger clip SpO2 Sensor
1X ECG 5-Lead Cable, Snap End, IEC Standard
1X Adult Reusable NIBP Cuff
1X Adult Reusable NIBP Tube
1X Adult Reusable Skin Temperature Probe
10X Disposable ECG Electrodes
1X Power Cable.
